High-Precision Stainless Steel Guide Rod CNC Turning - Custom Hardware Machining Services
Product Overview :
Our high-precision CNC turning services specialize in manufacturing custom stainless steel guide rods and non-standard hardware components with tight tolerances and superior surface finishes. Ideal for industrial automation, linear motion systems, and precision machinery, our CNC-machined guide rods ensure durability, corrosion resistance, and reliable performance in demanding applications.
Key Features :
✔ Material Expertise: Machined from high-grade stainless steel (304, 316, 17-4PH, etc.) for corrosion resistance and strength.
✔ Precision Turning: Tight tolerances (up to ±0.005mm) and fine surface finishes (Ra 0.4μm or better).
✔ Custom Solutions: Tailored to non-standard specifications—diameters, lengths, threads, grooves, and special geometries.
✔ Secondary Processing: Optional grinding, polishing, heat treatment, or coating for enhanced performance.
✔ Fast Prototyping & Mass Production: Supports both small-batch samples and large-scale orders.
Stainless Steel Guide Rod CNC Turning – Technical Specifications
| Parameter | Specification |
| Material | Stainless Steel 304, 316, 303, 17-4PH, 440C, or custom grades |
| Diameter Range | Ø3mm – Ø150mm (customizable) |
| Length Range | Up to 1000mm (longer lengths available upon request) |
| Tolerance | Standard: ±0.01mm | High-Precision: ±0.005mm (adjustable per requirement) |
| Surface Finish | Ra 0.4μm – 1.6μm (mirror polishing, grinding, or as required) |
| Straightness | ≤0.01mm/100mm (enhanced precision upon request) |
| Hardness | HRC 28-55 (heat treatable for higher hardness) |
| Processing Methods | CNC Turning, Milling, Grinding, Threading, Grooving, Knurling |
| Secondary Services | Anodizing, Passivation, Sandblasting, PVD Coating, Laser Marking |
| Certifications | ISO 9001, RoHS, PPAP (upon request) |
| MOQ | Prototype: 1 piece | Mass Production: Negotiable |
| Lead Time | Samples: 3-7 days | Bulk Orders: 10-25 d |
Applications :
-
Linear guides & motion systems
-
Automotive & aerospace components
-
Medical equipment & precision instruments
-
Industrial machinery & automation
FAQ :
1. What materials do you offer for guide rods?
We primarily machine stainless steel grades (304, 316, 303, 17-4PH, 440C), but can also work with carbon steel, aluminum, or titanium upon request.
2. What tolerances can you achieve?
Standard tolerance: ±0.01mm | High-precision: ±0.005mm or tighter (supported by grinding/post-processing).
3. Can you produce non-standard or custom designs?
Yes! We specialize in custom geometries, including threads, grooves, tapered ends, and special diameters/lengths. Provide your CAD/DWG files or samples for a quote.
4. What surface finishes are available?
-
Standard turning: Ra 1.6μm
-
Fine grinding/polishing: Ra 0.4μm or mirror finish
-
Coatings: Passivation, PVD, nickel plating, etc.
5. Do you provide secondary processing?
-
Heat treatment (hardening, tempering)
-
Grinding for ultra-precision
-
Anti-corrosion treatments (e.g., passivation)
-
Laser engraving or marking
6. What’s your MOQ?
